1978 78 Amc Gremlin Hornet 11x17 Full Color Laminated Wiring Diagram on 2040-parts.com
Carmel, New York, US
| This diagram is specific to 78 American Motors {AMC} Gremlin & Hornet models. As seen in Car Craft / Mopar Collectors Guide / Hemmings Muscle Machines / Classic Cars / Muscle Car Enthusiast & Auto Trader.
This is a generic sample diagram: The one you receive will be specific to your vehicle. |
| If
you are tired of those hard to read almost impossible to decipher black
and white wiring diagrams copied out of 30 to 40 year old shop and repair
manuals? This diagram is the solution!
We
have laminated wiring diagrams in full
color
for 30's 40's 50's 60's
& 70's American Cars and Trucks (and some imports). Being car enthusiasts ourselves, we understand how our product is used, and how important clarity and accuracy are. All information and color coding is from the original shop and service manuals. For example: if your car has a green wire, the circuit will be represented by a green line. Tracers are also shown. The diagrams show all of the basic components and connectors in the car. We are constantly adding cars to our database. If it is not listed, we can probably create it for you, in most cases within a few weeks. Just send us a quick note and we will reply with availability. Thanks for checking out our listings. If you have any questions please don't hesitate to shoot us a quick email! Copyright © 2001 - 2008 ClassicCarWiring.com. All rights reserved. |
