528 Hemi 800hp 426 Super Clean, Low Run Time Complete Engine Apart on 2040-parts.com

US $12,500.00
Location:

Oxnard, California, United States

Oxnard, California, United States

This engine is over $22,000 when new! The first photo is from the engine builders site to represent what parts we have for sale, what it looks like assembled.  Please refer to the our detail photos to make sure we have what you want. It is very complete.  You can't buy all these parts for this price.

It is a estimated 800hp 528 Hemi originally built by Ray Barton a few years back. It is apart and ready for inspection.  Oil pan is included but not shown. We will email a few more photos to serious buyer. In the photos you can see the amazing condition of the aluminum heads, block, crank, rocker shafts, valve covers, and so many other parts.  All with very low run time.

Why is it apart?  Good question..  We bought it as "new" "just broke it in" only to take a valve cover off later to notice some missing pushrods, which led to figure out that a cam bearing was spun.  We assume that on original install, cam bearing was clocked wrong, but you should confirm all this upon reassembly.  Our major loss is your major gain.  Sold the car after this heartbreak, so no interest or projects to use in in.

Shipping available worldwide, but can't use paypal for a transaction this high.  Paypal is for deposit only.  Inspection is highly encouraged but the price is so worth its a pretty safe bet. If you want to have it inspected or built in Southern California then bid to win and send your guy on over to inspect.  Contact me with questions and we will do what we can to accommodate your concerns.



Photo of engine on stand is from the original builder, Ray Barton

Engine description from Ray Barton web site, some details may be different:

Our 528" Single Plane Hemi's are designed to deliver power and durability on pump gasoline with a minimal amout of maintenance, making them excellent street/strip engines.  From carb to pan, these engines are equipped with top shelf part, giving you the most value and enjoyment out of your Hemi.  The RBRE Single Plane intake providesmore power and drivability compared to the average Hemi intake.

Bill Of Materials

Mopar Cast Iron Hemi Block

  • Blueprinted in house to our specs
  • High performance engine bearings

Hemi Aluminum Cylinder Heads

  • RBRE custom multi-angle valve job
  • Stainless steel high flow valves
  • High performance Hemi head bolt kit

Valvetrain Package

  • RBRE individual shaft rocker system
  • Trend 3/8" x .080" pushrods
  • Manley/Comp springs, retainers, cups

Oil System

  • Mopar 6 quart center sump oil pan
  • Mopar stroker windage tray
  • 1/2" Hemi oil pump pickup
  • Melling high volume oil pump
  • Distributor drive gear

Rotating Assembly

  • Internally balanced in-house
  • Rods & pistons are pin fit
  • 4340 Forged crankshaft
  • 4340 H-beam steel connecting rods
  • Diamond forged pistons
  • Moly ring set - 1/16" x 1/16" x 3\16"
  • crankshaft damper

Cam Package

  • RBRE custom ground solid cam
  • Billet double roller timing chain
  • ARP camshaft bolts
  • Tool steel solid lifters
  • Mopar chrome timing cover

Ray Barton Single Intake Manifold

  • intake manifold bolts
  • no Carburetor
  • carb stud kit



RBRE Cast Aluminum Valve Covers

  • Mopar performance spark plug tubes
  • breathers
  • valve cover bolts

MSD Billet Distributor

  • Mopar distributor clamp
  • custom spark plug wires

Gaskets

  • RBRE custom gasket set
  • Cometic MLS head gaskets




Highlights:



  • Ultimate street/strip engine
  • Produces more power without sacrificing durability
  • Ported heads increase power & RPM range
  • Custom cam Idles & sounds like a Hemi should
  • Titanium retainers included for more durability
  • 10:1 Compression for pump gas
  • All new parts from brands you know and trust
  • Minimum amounts of maintenance
  • Fits all stock Hemi accessories
  • Standard exhaust port location
  • Dyno tested - We encourage you to come see it run
  • We have built 100's of them


Upgrades & Accessories



  • Port match intake manifold
  • 7 Quart oil pan
  • 8 Quart custom aluminum oil pan
  •  distributor
  • Flexplate & ARP bolt package
  • Torque converter
  • Flywheel & ARP bolt package
  • Hemi K-frame
  • Hemi motor mounts


On May-27-16 at 09:09:57 PDT, seller added the following information:

Intake Manifold is included but not shown in photos, can send you photo if bidding.  Its just as clean as the rest of the items.
