8 Black Parking Sensors Car Vehicle intelligence  Reverse Backup Radar Alarm Buzzer System with Double LCD Display

Features

Automotive radar collision avoidance system for automotive exercise berths safety auxiliary devices. The system is equipped with an ultrasonic sensor, and can accurately detect whether there is an obstacle after the car. Its principle is to use the command and control operation of the microcomputer system, respectively, suggest azimuth and distance to the obstacle between the body and through the sound barrier and monitor, secure parking

Unique Features:

◆ The new upgrade, dual digital display, dual-core reversing radar,
reversing after starting the car while four of the probe, will start before the car
around the edge of the two probes, to prevent reversing rub angle, more safe and accurate
◆ The Smart Start function: new design, more intelligent, when braking, the radar starts,
there are obstacles into the detection area, the monitor will start work. More humane, more scientific.
◆ Multi-function button: Provides voice switch button, users can switch key display,
can be muted, beeps, voice, or four voice + buzzer sound mode, switch between.
◆ Sound button: 7 files provided for the user to sound regulation, only true dual-core can.
◆ Display new design: BMW adapter, separate design, solve the big problemHow does the 8-sensor system work:
• While braking, all 4 front sensors will be active. While reversing, 2 front & 4 rear sensors and LCD monitor will be active.

Tech Spec:
• Detection Angle: H＞80°, V＞90°
• Rate Voltage: 12V
• Front Sensor Detection Range: 0.98~3.28 ft
• Rear Sensor Detection Range: 0.98~7.54 ft

3 Alarm Modes:
• Beep: the closer the obstacle, the more rapid the sound.
• Matrix Light Bar: heartbeat tips to remind obstacle distance.
• Digital: precise figures shown on LCD screen.

Important Notice:
• For safety reasons, while braking, only the sensors sense obstacles, the LCD monitor will be active.
• Try to keep the sensors at the same level.
• In order to avoid detecting the ground, please keep the sensor and the ground has a distance of 19.6~23.6 in (21.6 in suggested).
• Please always keep the arrow (back of each sensor) up while installing.
• The Control Box should be mounted on side of the car trunk.

Installation Tools Required:
• Hole Saw (package included)
• Drill
• Needle Nose Pliers
• Thin Steel Wire
• Rasp
• Tape measures
• Marker Pen
• Screwdrivers
• Electrical Tape

Package Includes:
• 1 x Control Box
• 1 x LCD Monitor
• 1 x LCD Extension Cable (17.39 ft)
• 6 x Parking Sensors (cable: 8.2 ft)
• 4 x Front Sensor Extension Cable (14.76 ft)
• 1 x Power Cable (9.84 ft)
• 1 x Hole Saw (22mm / 0.85 in)
• 1 x User Manual
• 1 x Control Box Sticker
