Cylinder Scoring is a serious damage,which caused by improper use and will cost you a lot of money to repair the motor.
Don't do the following will avoid cylinder Scoring:
1start the motor on bank
2, use the motor when it stop coming out of water
Even if you want test the motor, it should be done in the river!
Notice:Please add gear oil to the gears before use the motor and replace gear oil after the run-in period(10 hours).(if you do not know how to handle this,please contact us).our outboard motor doesn't with oil of gear,please prepair it by yourself .Keep in mind that you must add oil on the gear beofore use !!!
About certification:
We can only provide CE certification, there is no other certification can be provided,thanks for your understanding.
Announcements
After in the sea water or turbid water cruising
1. Use the fresh water cleaning the outboard motor
2. With the moderate velocity circulating the engine,cool off the water chanel with fresh water.
3. Before completely running out cooling water,don't put the outboard motor outside. Otherwise the water cam pass the exhaust port to enter the air cylinder, from that will cause the engine breakdown.
4. The engine should deposit in the aridity and ventilated well place,avoid exposing directly in the sunshine.
5. Before the long term storing,you should run out of the gasoline in the fuel tank.
Two strokes 3.5 hp and 3.6 hp are controlled by the handle, which is operated by the clutch. There is no Neutral, only idle mode or low speed mode
Please Note:
There are two pull starter included in the parcel(one is the machine, another one for spare)
We don't supply wearing parts (pull starter)for free.
If you want buy one please click:
Description:
Overall length:92CM
Overall widteh:36.5cm
Overall height:22cm
Transom height:42cm
Full throttle perating range:4000-5000r/min
Speed:10km/h
Type:2-stroke
Ignition system: CDI system
Starting system: Manual start
Staring carburetion system: Choke start
Propeller mark:7-1/45-A(inch)
The engine and the propeller ratio:2:1
Recommended fuel: Regular unleaded gasoline
Fuel to oil ratio: 35:1 Please be suject to this version, and disregard the manual about this point
Gear ratio: 27/13
Maximum speed: 10 km / h
Built-in fuel tank: 1.3L
Fuel consumption per hour: 1.5L
When at normal cruising, the appearance of the seventh picture. Falling back the boat, the appearance of the outboard motor likes the eighth picture . Falling back the boat, you should drive slowly otherwise the boat will not stable. The outboard motor backet can revolve 360. Only in simple let the engine revolve 180 and the operation handle face back, the boat can fall back to drive.
Announcements:
After in the sea water or turbid water cruising
1.Use the fresh water cleaning the outboard motor
2.With the moderate velocity circulating the engine,cool off the water chanel with fresh water.
3.Before completely running out cooling water,don't put the outboard motor outside. Otherwise the water cam pass the exhaust port to enter the air cylinder, from that will cause the engine breakdown.
4.The engine should deposit in the aridity and ventilated well place,avoid exposing directly in the sunshine.
MODEL TWO: 4HP & 4-Stroke,Air-cooling System
SKU: OT-ML-277
Type: 4 stroke 4 horsepower
Capacity: 52cc
Transmission ratio: 2.08 (27:13)
The number of cylinders: 1
Maximum speed: 4000-5000
Maximum power: 2.8 kW /4 HP
Shift position: clutch control
Package volume: 95x40x30 cm
Ignition system: CDI
Cooling system: air cooling
Starting method: Manual start
Refueling: No. 93 gasoline
Propeller size: 7 1/4X7-A
The maximum fuel consumption: 1.4 liters / hour
Recommended Lubricant:4 stroke lubricating oil
Mixing ratio:Pure gasoline
Trim and tilt system:Manual Tilt
Start-In-Gear protection/clutch feature prohibits prop rotation while idling convenience
without reverse gear,Features 360 degree steering rotation for reverse without gear shifting
Cooling system: air cooling
Easy pull off engine cover with push button latch for instant motor access
Must read before use!
Four stroke 4 hp:
Firstly, Fill the gear oil (open gear box lid and fill it).
Secondly, Fill NO. 92 petrol, lightly press oil pump 6-10 times.
Thirdly, Fill engine oil don't exceed the head of the pattern.
Forthly, Pull the gear to netural gear, and plug the brake line in, hang the other side of the brake line on your wrist at the same time.
Then, turn the accelerator gets up to 50% and rapidly pull the starter line.
After the motor start, please turn the gear to minimum before put another gear. Otherwise, the gearwheel will be broken if you put high gear.
Description:
Long shaft : 50cm
Universal motors, high performance, reliable quality
Perfect match inflatable boats, fishing boats, sailboats, and small yachts.
Economical and compact structure. Durable, lightweight and anti-corrosive construction.
Maneuverable and safe twist grip throttle control.
Suitable for: Freshwater and saltwater
One year warranty covers the motor, to provide parts free
Type: 4 stroke 7 horsepower
Capacity: 196cc
Transmission ratio: 2.08 (27:13)
The number of cylinders: 1
Maximum speed: 4500-5500
Maximum power: 5.1 kW /7 HP
Shift position: clutch control
Package volume: 120x60x42.5 cm
Ignition system: TCI
Cooling system: air cooling
Starting method: hand start
Refueling: No. 93 gasoline
Propeller size: 3-7 1/2''x5''
Gear position:F-N-R
Control system: Tiller control
N.W./G.W.:26.7/31.7kgs
Recommended Lubricant4 stroke lubricant oil
Trim and tilt system:Mannual tilt
Standard fuel tank capacity:1.4L/within
Two strokes 3.5 hp and 3.6 hp are controlled by the handle, which is operated by the clutch. There is no Neutral, only idle mode or low speed mode
Please Notice: STRICTLY FOR PROFESSIONAL USE ONLY
What you will receive is our new version of this boat engine
The trademark will be Yadao instead of Speeda.
Short Shaft:4 0cm
Overall length: 83cm(32.68inch)
Overall widteh: 36.5cm
Overall height: 22cm
Transom height: 42cm
Full throttle perating range: 4000-5000r/min
Maximum output: 2.5kw(3.5HP)
Speed: 12km/h(four people)
Type: 2-stroke
Ignition system: CDI system
Starting system: Manual start
Staring carburetion system: Choke start]
Propeller mark: 7-1/45-A(inch)
The engine and the propeller ratio: 2:1
Recommended fuel: Regular unleaded gasoline
Fuel to oil ratio: 35:1 Please be suject to this version, and disregard the manual about this point
Gear ratio: 27/13
When at normal cruising,the appearance of the seventh picture. Falling back the boat, the appearance of the outboard motor likes the eighth picture. Falling back the boat, you should drive slowly otherwise the boat will not stable. The outboard motor backet can revolve 360. Only in simple let the engine revolve 180 and the operation handle face back, the boat can fall back to drive.
Announcements:
After in the sea water or turbid water cruising
1. Use the fresh water cleaning the outboard motor
2. With the moderate velocity circulating the engine, cool off the water chanel with fresh water.
3. Before completely running out cooling water,don't put the outboard motor outside. Otherwise the water cam pass the exhaust port to enter the air cylinder, from that will cause the engine breakdown.
4. The engine should deposit in the aridity and ventilated well place,avoid exposing directly in the sunshine.
5. Before the long term storing,you should run out of the gasoline in the fuel tank.
About certification:
We can only provide CE certification, there is no other certification can be provided,thanks for your understanding.
Brand: HANGKAI
Displacement: 123CC
Gear ratio: 2.08(27:13)
Cylinder: 1
Max.Output(kw): 4.8
Max.speed(r/min): 5000-6000
Gear Positions: F-N-R
Packing size: 114x64x41cm
Ignition System: CDI
Cooling System: Water-cooling
Control System: Tiller control
Starting System: Manual start
Control System: #93 gasoline
N.W./G.W.(kgs): 26/31.2
Bore x Stroke(mm): 59x45
Recommended Propeller range: 3 -7.8"x8"
Recommended Lubricant: Four Stroke Lubricating oil
Mixing ratio: Pure gasoline
Trim and tilt system: Manual Tilt
Overall LxWxH(cm): 78.3x34.3x103.9
Standard fueel tank capacity: 12L
Optional fuel tand capacity: /
Bonus accessories:
brochures, tubing, cotter pins
Pump impeller, start rope, start key
12 liter fuel tank, tool kit, spark plug, cylinder head pad
Two strokes 3.5 hp and 3.6 hp are controlled by the handle, which is operated by the clutch. There is no Neutral, only idle mode or low speed mode
Short Shaft: 40cm
STRICTLY FOR PROFESSIONAL USE ONLY
1. Start-In-Gear protection/clutch feature prohibits prop rotation while idling.·
2. Lift/Tilt feature for shallow water operation and convenience.
3. Features 360 degree steering rotation for reverse without gear shifting.
4. Superior engine water cooling system for improved engine performance.
5. Easy pull off engine cover with push button latch for instant motor access.
Product Description:
Start-In-Gear protection/clutch feature prohibits prop rotation while idling .
Lift/Tilt feature for shallow water operation and convenience . Superior engine water cooling system for improved engine performance. Easy pull off engine cover with push button latch for instant motor access. Standard CDI ignition system for easy starting and improved performance. Vertical mount engine design for increased power, performance and durability. Superior carbonation system with primer bulb for increased efficiency.
Twist grip throttle handle and engine stop button for improved response .
Superior outboard anti corrosion system and anodes for increased durability .
Durable cast aluminum construction for superior corrosion protection .
Through the prop exhaust outlet for decreased noise and pollutant .
Heavy duty lightweight aluminum cast propeller is standard equipment
Shipping Weight: 21.4 pounds
Description
Have you encountered any difficulties in venturing into long-distance deep water? An outboard motor that can handle various complex water conditions can provide you with assistance! The powerful 6-horsepower two-stroke engine allows you to overcome obstacles in various environmental waters and quickly reach the places you need to go with excellent speed. The large-capacity fuel tank also eliminates the hassle of frequent refueling. With its companionship, you can fully enjoy the pleasure of sailing and become a reckless captain!
Key Features
Fast & Powerful: A 2-stroke engine with a maximum output of 4.4kw and 6hp, and a maximum speed of 5500rpm, provides you with unparalleled speed. The streamlined design of a 7'' three-blade propeller can reduce water resistance and provide stronger power during operation.
Selected Material: Lightweight and sturdy aluminum alloy, combined with spray painting technology, provides excellent corrosion resistance, wear resistance, heat resistance, shock resistance, deformation resistance, and other properties. You can use it with confidence in fresh water and salt water.
Easy to Operate: The throttle lever directly controls acceleration and steering. The step-less speed regulation allow you to easily adjust the running speed, combined with simple gear shifting (forward, neutral, or reverse), bringing you a more comfortable and convenient user experience.
Low Noise: The large muffler above can isolate most of the noise, making the sound of the machine running around 80 decibels, allowing you to hear other movements on the water and remain vigilant.
Small & Fuel-efficient: As an outboard motor, it is relatively small(43.3*14.56*21.26in) and lightweight(45.3lbs), making it very suitable for small ships and people who frequently navigate short distances. An efficient carburetor burns fuel more fully, with a fuel consumption rate of 0.66gal/h not only saving fuel but also reducing expenses.
Safe & Reassuring: The reliable CDI ignition system can quickly and safely start the motor, and suspension tilt adjustment pins and anti-vortex plates reduce inclination and vortices, ensuring smooth operation. The water cooling system is designed to maintain the optimal temperature, coupled with overheating protection, allowing you to continuously enjoy the fun of the navigation.
Complete Set: In addition to the outboard motor, our package also includes a funnel, manuals, safety rope, etc., which can meet your usage needs at once.
Protective Packaging: This product comes in a custom foam that resists common compression and falls to prevent product damage in transit as much as possible.
Details
Locking Handle: The locking handle below the muffler allows you to easily open the casing to check the internal motor.
Tail Plate Clamping Bolt: It can firmly fix the outboard motor on your ship and is not easy to slide.
Rubber Handle Cover: The rubber-wrapped handle is softer and increases friction, providing a more reliable grip.
Cooling Water Outlet: You can determine whether the water pump is working properly by checking whether it is producing water, to promptly repair the engine if it may malfunction.
Application
It is suitable for rubber boats, inflatable boats, fishing boats, sailboats, yachts, canoes, kayaks, rubber boats, aluminum alloy boats, etc. with a stern height of 17.32 inches or less, assisting aquaculture, water transportation, net fishing, luring, outboard backup, outings, and river cleaning/maintenance.
Specifications
Material: Aluminum Alloy
Color: Black
Surface Treatment: Spray Paint
Assembly Required: No
Number of Items: 1
Engine: 2-stroke 6hp
Displacement: 102cc
Gear Ratio: 2.08(27:13)
Number of Cylinder: 1
Max. Output: 4.4KW
Max. Speed: 4500-5500r/Min
Noise: About 80DB
Gear Positions: F-N-R
Ignition System: CDI
Cooling System: Water-cooling
Control System: Tiller Control
Starting System: Manual Start
Gasoline: No.92 Lead-free Gasoline
Fuel Type: Mixed Oil (50 Gasoline: 1 2-stroke Engine Oil)
Trim And Tilt System: Manual Tilt
Fuel Tank Capacity: 2.5L/0.66gal
Fuel Consumption Rate: 2.5L/0.66gal/h
Bore*Stroke: 5.5*4.3cm/2.16*1.7in
Propeller Diameter: 18cm/7in
Handle Length: 36cm/14.17in
Adaptive Transom Plate Height: ≤44cm/17.32in
Gross Weight: 24.15kg/53.24lbs
Net Weight: 20.55kg/45.3lbs
Product Size: 105*48*24cm/41.3*18.9*9.4in
Package Size: 110*37*54cm/43.3*14.56*21.26in
Package Included
1x Outboard Motor
1x Flameout Rope
1x Tool Kit
1x Fuel Oil Mixing Bottle
1x Funnel
1x English Manual
1x English Operation Instructions
All Accessories for Assembly
Notes
1.Please carefully read the manual and strictly follow the precautions to have a better experience.
2.Please measure the height of your boat before purchasing to ensure suitability for this product.
3.Please start the motor in the water. If the motor stops circulating water, please stop using it immediately and check the impeller of the water pump to see if the water outlet is blocked.
4.Please note that this product should use a mixture of two-stroke engine oil and 92 # unleaded gasoline. The running-in period of the new machine is 10 hours, during which the fuel ratio is 30L (7.93 gal) of gasoline to 1L (0.26 gal) of engine oil. After 10 hours, the ratio is 50 liters (13.21 gallons) of gasoline to 1 liter (0.26 gallons) of oil.
5.Please note that the emergency shutdown rope should be inserted when the outboard motor is started, and the other end should be wrapped around your wrist or belt.
6.Please do not drive too fast during the running-in period. After the running-in period, the gear oil needs to be replaced, and the second replacement time is about 100 hours or 6 months later.
7.Please do not leave this product outside until the cooling water is completely used up. Otherwise, water will enter the cylinder through the exhaust port, leading to engine failure. After cruising in seawater or turbid water, please clean the outboard motor with fresh water and cool the water channel with fresh water. The engine should be stored in a dry and well-ventilated place, and avoid direct exposure to sunlight.
8.If not in use for a long time, please thoroughly clean the gasoline in the fuel tank.
9.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
Please Note:
There are two pull starter included in the parcel(one is the machine, another one for spare)
We don't supply wearing parts (pull starter)for free.
If you want buy one please contact us
Short Shaft:40cm
Description:
Overall length:92CM
Overall wideth:36.5cm
Overall height:22cm
Transom height:42cm
Full throttle perating range:4000-5000r/min
Maximum output:2.5kw(3.5HP)
Speed:10km/h
Type: 2-stroke
Ignition system: CDI system
Starting system: Manual start
Staring carburetion system: Choke start
Propeller mark:7-1/45-A(inch)
The engine and the propeller ratio:2:1
Recommended fuel: Regular unleaded gasoline
Fuel to oil ratio: 25:1 Please be suject to this version, and disregard the manual about this point
Gear ratio: 27/13
Maximum speed: 10 km / h
Built-in fuel tank: 1.3L
Fuel consumption per hour: 1.5L
