4HP 4 Stroke Outboard Motor Fishing Boat Engine with Air Cooling System CDI
Specification
Material: Aluminum, Plastic
Color: Black
Type: 4 Stroke 4 Horsepower
Shift Position: Clutch Control
Ignition System: CDI
Cooling System: Air Cooling
Starting Method: Manual Start
Refueling: No. 93 Gasoline
Propeller Size: 3-7 1/4X7-A
Recommended Lubricant: 4 Stroke Lubricating Oil
Mixing Ratio: Pure Gasoline
Trim and Tilt System: Manual Tilt
Transmission Ratio: 2.08 (27:13)
The Number of Cylinders: 1
Standard Fuel Tank Capacity: Within 1.4 L/0.37gal
Fuel Consumption: About 1L/H / 0.26gal/H
Maximum Power: 2.8 kW /4 HP
Maximum Speed: 4000-5000rpm
Capacity: 52cc
Short Shaft Length: 40cm/15.75in
Fitted Stern Plate Height: 44cm/17.32in or Less
Recommended Load Capacity: 750kg/1653.47lbs
Gross Weight: 13.4kg/ 29.54 lbs
Net Weight: 9.7kg/ 21.38 lbs
Product Size: 92*36.5*22cm/36.22*14.37*8.66in
Package Volume: 95*42*29cm/37.40*16.54*11.42in
Package Included 1*4 Stroke 4HP Outboard Motor Boat Engine 1*English Manual 1*Funnel 1*Toolkit 1*Split Pin |  |
Product Description
|  |
Feature:
|  |
Machine details
|
|
|
|
|---|---|---|---|
 | Additional Information:
|
Description
This product has a strong power of 4HP with four-stroke, which enables you to drive fast and save a lot of time and energy. It also has a 360-degree steering function, which is very easy to operate. The large capacity fuel tank also reduces the number of times you have to refuel, thus increasing your efficiency. It will be your most powerful assistant when you are sailing at sea.
Key Features
High-quality Material: The product made of high-quality aluminum alloy and plastic has high hardness, anti-corrosion, and anti-rust properties, which can effectively extend the life of the product.
Powerful: The 4-stroke 4hp engine can rotate up to 5000rpm, which is powerful enough for you to drive quickly and save a lot of time and energy.
Easy to Operate: The simple manual start method and the detailed English manual inside the product package can help you operate easily and accurately. All you need to do is pull the rope and you're ready to start.
Easy to Carry: The outboard with a size of 36.22*14.37*8.66 inches has a compact body, which is easy to carry on the go. You can easily store it in the trunk of your car.
Fast Heat Dissipation: The large heat dissipation holes on the engine housing can help dissipate heat quickly and prevent the engine from burning after a long period of use, thus effectively extending the life of the engine.
Flexible Steering: This product has a 360-degree steering function and clutch control, which can easily control the steering of the boat.
Good Noise Reduction Effect: Compared with two-stroke, the four-stroke outboard has a better noise reduction effect. It can provide you with a quieter working environment.
Low Fuel Consumption: This product adopts new fuel saving and has a low energy consumption of 0.26 gal/H. This can help you save a lot of energy and money.
Air Cooling System: It cools fast and has a low failure rate. There is almost never leakage, which will not make oil and water mix and damage the oil pump.
Details
Three-blade Propeller: The Three-blade propeller with streamlined design can reduce water resistance and provide stronger power during operation.
Large Capacity Fuel Tank: The 0.37-gallon fuel tank can effectively reduce the number of times you have to add fuel, thus increasing your efficiency.
Baffle: The baffle above the propeller can effectively reduce the bumps of the waves and avoid water from getting the boat board wet.
Application
This product is suitable for small boats of different materials (such as inflatable boats, iron boats, plastic boats, fiberglass boats, and wooden boats), and is applicable to water operations in rivers, lakes, reservoirs, fish ponds, etc. It is applicable to ships with a load of about 1653.47 pounds and a stern plate height of 17.32 inches or less.
Notes
- Gasoline is prone to oxidation and degradation when stored. Using degraded gasoline will clog the fuel line and cause starting difficulties. If the engine has not been used for more than half a month, please drain the fuel in advance.
- Please add gear oil to the gears before using the motor and change the gear oil after the break-in period (10 hours).
- The speed is slower when the boat is heavier loaded.
- The propeller can withstand fresh water and salt water, but after using it in salt water, you must clean it with water immediately.
- Please store the engine upright with the engine side up, not upside down. Otherwise, the oil may flow into the engine combustion chamber and cause engine damage.
- Please do not start the motor on the shore where there is a lack of water. Even if you want to test the motor, you should do it in the river!
- The four-stroke outboard oil tank can only be filled with pure gasoline, and the oil tank should use special oil for four-stroke (car and motorcycle oil are both available). The oil should be filled according to the scale on the dipstick (the upper scale is the upper limit, and the lower scale is the lower limit, do not add more or less oil, add about 0.09 gal of oil)
- Before each use of the machine, please check whether the oil is sufficient, and check the air filter before each use.
- It is prohibited to idle in a bucket of water to break in, and idle speed is prohibited to be higher than five minutes during the break-in period! The long idle time during the break-in period may produce carbon, which will burn off the spark plug and lead to late starting difficulties.
- Please read the operating manual completely before use. And pay particular attention to the safety instructions included.
- Please allow the slight color difference caused by the shooting light and the 1-3 cm error due to manual measurement, and make sure you do not mind before ordering.
