CHEV 496/650HP
Hi Performance Balanced Engine
With Aluminum Heads

FREE professional crating and shipping in
the continental US if you use "Buy it Now"!
This is a  retail savings of $200 to $600 !

This Chevy 496 650HP crate engine by Tuff Dawg Engines would be EXCELLENT for a street/strip car, street rod, pickup, or jet boat and runs on leaded or unleaded premium pump fuel. With 650HP @ 6200rpm and 600 ft lbs of torque @ 4700rpm it will set you back in the seat. With it's roller cam and 4.250" stroke it has amazing torque at all speeds. This engine still has 550 ft lbs of torque @ 3500rpm!

The balanced rotating assembly includes:

• New 4.250" stroke & index steel crankshaft with .125" radius for added strength
• New 6.385" Forged I-beam rods
• New 10½ to 1 Forged dome pistons
• New file-fit moly rings
• New Race style harmonic balancer

More special features of this engine include:

• Seasoned 4-bolt main block
• New CompCams mechanical roller camshaft
• New CompCams mechanical roller lifters
• New Aluminum rectangular port heads
• New 2.250"Int/1.880"Exh stainless valves with 11/32" undercut stems that have been swirl polished for improved flow
• New High performance roller valve springs setup to match roller cam
• New Heavy duty 1.7 full roller rocker arms with 7/16" screw-in studs and 7/16" guide plates to handle that big roller cam. These roller rockers are fully CNC machined with anodized finish. Needle bearing fulcrums and roller tips. Centerless ground pin and roller pedestal machined from billet steel. Thick wall poly lock nuts are used for adjusting
• New ⅜" chrome moly push rods
• New Double row timing set with Torrington bearing or thrust wear spacer
• New Timing cover with button to prevent cam walk
• New Hardened racing main and rod bearings with big chamfer to clear .125" radius on steel crank
• New Oil pump with steel drive shaft and steel guide with welded oversize pickup to match oil pan
• New 7 quart drag/race oil pan
• New Brass expansion plugs
• New Edelbrock Victor Jr single plane aluminum rectangular port high rise intake manifold - This intake offers maximum horsepower with a broad torque curve for great all around power
• All parts are painted separately before assembly for the show quality you need for that special show car or street rod

This engine comes completely assembled with drag/race oil pan, chrome dipstick, aluminum billet timing cover with chrome timing marker, harmonic balancer, chrome valve covers, and Edelbrock single plane aluminum intake manifold.

This engine is custom built from start to finish in our state of the art facility by professionals that take pride in their work to guarantee that you get a top quality engine the first time!.

Here at D&J MACHINE & PERFORMANCE ENGINES we have over 38 years experience in building top quality affordable, streetable, performance engines.

Purchase:

"Buy it Now" for $7495.00. AZ residents add 8.3% tax. No core required!

Shipping:

Residents of the continental United States will get FREE shipping to your home or business address that is accessible by a tractor trailer rig! This is a retail savings of $200.00 to $600.00 in professional crating and shipping costs!

International shipping available, please contact us. D&J Machine will not be responsible for any customs delays or fees. ALL tariff and tax charges are the responsibility of the purchaser!
