FORD 390 4x4 TURNKEY
WITH EZ-EFI^® SYSTEM
Hi Performance Balanced Engine
1965 to 1976

FREE professional crating and shipping in
the continental US when you "Buy it Now"!
International shipping available please contact us!

Update your old ride with a Tuff Dawg EFI engine with todays technology! This Ford 390 EZ-EFI^® turnkey crate engine by Tuff Dawg Engines is custom built with a camshaft to match your application and use and would would be EXCELLENT for your 1965 to 1976 4x4 pickup. Remove that old Ford 352, Ford 360, or Ford 390 and install this Ford 390 to bring your 4x4 to life! This Ford 390 is a direct bolt-in, no modifications are needed! This Ford 390 puts the focus on torque where you need it most in a 4x4. This engine will run on leaded or unleaded Premium fuel.

The balanced rotating assembly (typically includes crankshaft, pistons, rings, connecting rods, rod bearings, and balancer) featured in this engine:

• 3.780" stroke nodular iron crank
• 6.488" big beam forged rods with ARP rod bolts
• 9½ to 1 compression pistons

More special features of this engine include:

• Seasoned 2-bolt main block
• Deck head gasket surface on block to ensure a good seal
• New Hydraulic flat tappet cam that is designed to produce strong torque with excellent throttle response in a heavy body 4x4 which we will custom match to your specific application and use
• Heads have 2.030"Int/1.560"Exh valves
• New Hardened exhaust seats for use with leaded or unleaded fuel
• New 1.440" high performance springs set up to match cam
• New Spiral-type valve guides for better oil retention
• New Perfect Circle rings
• New Double row timing set
• New Oil pump with steel drive shaft and bolt on oil pickup tube
• New Brass expansion plugs
• New Edelbrock Performer RPM aluminum intake manifold. This dual plane intake constant cross-sectional area design builds low end and mid-range acceleration while optimized runner path make top-end hp
• All parts are painted separately before assembly for that show quality look

This engine comes completely assembled with 4x4 oil pan, timing cover, harmonic balancer, valve covers, and intake manifold.

This Is A Real Turnkey Engine

This engine has been started on gas and run. The camshaft has been broken in and the valves adjusted. The 4150 throttle body and timing has been initially set, but should be checked after installing in vehicle.

Also included and installed on engine:

• New EZ-EFI^® self tuning fuel system. Complete package including ecu, throttle body, fuel rails, wide band O₂ sensor, wiring harness, fuel injectors, and electric fuel pump. The easy to use setup wizard provides a comprehensive walk through and the system tunes itself.
• New Electric fuel pump.
• New Fuel regulator
• Chrome air cleaner
• Fuel filter
• New MSD Pro-Billet distributor, MSD 6AL box, and MSD Blaster coil
• Spark plugs and spark plug wires
• Water pump
• Crankshaft and water pump pulleys
• Alternator with bracket and alternator belt
• Starter
• Water outlet and thermostat
• Starter alignment plate for back of block
• A/T Flexplate with bolts
• This engine has been started on gas and run. The 4150 throttle body and timing has been initially set, but should be checked after installing in vehicle.

Not included on this engine:

Exhaust manifolds, hoses, fan, accessory belts (except alternator belt), radiator, linkage or miscellaneous.

This engine is custom built from start to finish in our state of the art facility by professionals that take pride in their work to guarantee that you get a top quality engine the first time!.

Here at D&J MACHINE & PERFORMANCE ENGINES we have over 38 years experience in building top quality affordable, streetable, performance engines.

Purchase:

"Buy it Now" for $9,595.00. AZ residents add 8.3% tax. No core required!

Shipping:

Residents of the continental United States will get FREE shipping to your home or business address that is accessible by a tractor trailer rig!> This is a retail savings of $200.00 to $600.00 in professional crating and shipping costs!

International shipping available, please contact us. D&J Machine will not be responsible for any customs delays or fees. ALL tariff and tax charges are the responsibility of the purchaser!
