Kus Boat Trim Gauge Wema Outboard Marine Trim Gauge 52mm 12v/24v Up-down on 2040-parts.com

US $15.90
Location:

余姚市, 浙江省, China

余姚市, 浙江省, China
Condition:New Brand:KUS Bezel:Stainless Steel Manufacturer Part Number:KY09028 Indicating Range:UP-DOWN Other Part Number:KY09028 Signal:0-190Ω Placement on Vehicle:Left, Right, Front, Rear, Upper, Lower Mtg Hole:2-1/16" (52mm) Warranty:Yes Face:Black Country/Region of Manufacture:China Working Volt:12/24V UPC:Does not apply

2nq9zex



KUS Boat Trim Gauge WEMA Outboard Marine Trim Gauge 52mm 12V/24V UP-DOWN

* Provides information about the position of the engine in relation to the boat's stern. It can also give a signal to avoid damage caused to the prop while sailing in shallow water
* Use moving-magnet principle to drive the needle, featuring good endurance and anti-vibration
* Style(as left pictures,Remark:SS=stainless steel): SS & black(BS),black SS & black(BN),SS & White (WS),balck plastic&black(BB), white plastic & white(WW)
* Bezel Material:316 Stainless Steel or plastic,cured glass
* Installation Dimension: Φ52mm(2”)
* Installation: lock the gauge to baseboard directly by hand
* Connector: multi-plugs socket connection
* Background light: Red or Yellow
* Indicating Range:UP - DOWN & DOWN - UP
* Working Voltage:12/24V
* Signal:0~190Ω
* Protection grade:IP7;can work up to 1m under water

Technical Trouble Shooting
Q: Why is the level gauge reading backwards (reading full when tank should be empty, reading empty when tank should be full)?
  • That means the gauge and the sending unit are using different standards (one may be using American standard, 240 ohm at empty, 30 ohms at full; the other may be using European standard, 0 ohms empty, 180 ohms at full), hence, are not compatible.
  • Only solution would be to replace either the gauge or the sending unit so that both are using either European Standard or American Standard ohm range.
Q: Does Wema carry a fuel sender that can be shortened in length?
  • Yes, the length of the High Resolution Capacitance Level Sensor (CLS) can be shortened and signal output re-calibrated.
Q: What lengths do the standard units come in?
  • SSS/SSL
    • Available 4" through 18.5" at 0.5" increments
    • Available 19" through 60" at 1" increments
  • S3U and S5U
    • Available 4" through 60" at 1" increments
  • SHS/SHST
    • 4", 6", 8", 12", 16", 18", 20", 22", 24", 28", 38"
Q: Are the level senders or gauges NMEA 2000 certified or compatible?
  • Currently the gauges are not compatible with the NMEA 2000 system. The level senders can be made compatible by connecting it to a signal converter module.
Gauges
Q: What are the input signals for the gauges?
  • The signal input for our stock gauges are 240-33 ohms American Standard and 0-180 ohms, European Standards
Q: What type of signals does the Tachometer take?
  • The tachometer can process both sine and square signals.
Q: What is the operating voltage for the gauges?
  • The gauge can work with both 12V and 24V systems. When connecting to a 24V system, certain gauge will require a drop resistor on the connection between the power and the gauge.
Q: How to test if the level gauge is operating correctly?
  • Make sure power to the gauge is not on.
  • Disconnect the black wire on the gauge to the sender. Leave enough wire at the gauge end to work with.
  • Turn on the power to the gauge
  • Inspect the
    • American standard gauges (240-30 ohms) will show Empty. Ground the black wire, and the needle will go to Full
    • European standard gauges (0-180 ohms) will show Full. Ground the black wire, and the needle will go to Empty
Q: How come the Navigation Gauge is not working?
  • If you recently switch the bulb on your vessel from incandescent bulbs to the equivalent LED counterparts, you need to reconnect the wires from the B1-B5 terminal to the L1-L5 terminal. Please see attached instruction.
Q: Are the gauge dials backlit?
  • Yes, the gauge dials are backlit with LEDs.
Q: Do the gauges only work with Wema senders and sensors?
  • No, the gauges can work senders and sensors from other companies as long as both are compatible (both American standard units, or both European standard units).
